HOME > PRODUCT > M302 NFC Plug & Play Module

M302 HF reader module fully support 13.56MHz contactless card & fashionable NFC ISO18092 mobile phone for embedded application, which offer a low-cost and robust method of authentication for consumables, making ideal for medical, ticketing, security or other safety&identity applications.



M302 has multi-port as USB and serial port for external communication and integrates all necessary components to driver directly matched antenna in integrated or external format.



Highlights

● 13.56MHz HF RFID ISO14443A/B,ISO15693, Mifare plus, DesFire EV1

● ISO18092 Near Field Communication (NFC) with build-in ISO7816 (T=0 T=1) SAM

● Multi Communication Interface for flexible integration as wiegand, TTL and serial port

● Selective card polling capability in multi block transfer

● Firmware updates via serial interface (loader required)

● Diversified integration platform: Windows 98/2000/XP/7; Vista; Server2003&2008, ME98; Linux;  WinCE 6.0 above / CE.net

● Comprehensive development kit and testing environment by XID


                                                                              M302 OEM Plug & Play NFC & HF Module

ISO14443A MIFARE®
MIFARE® Classic 4K, MIFARE® Pro(X), SLE55Rxx, SLE66CL160S, JCOP, Other
compatible cards;MIFARE Ultralight®,MIFARE UltralightC®

MIFARE®,DESFire® EV1
MIFARE®,MIFARE Plus®

ISO14443B
SRI512, SRI2K, SRI4K, SRIX4K,
CEP AS (CSN)

Sony FeliCa™
Non-Secure FeliCa™, Innovision Topaz

ISO18092 NFC
NFC forum tags, ISO/IEC 14443-4 PICC type Aand type B

ISO15693
I-CODE ILT-M, I-CODE SLI-L/S, Tag-It, My-d, EM4035, HID iCLASS UID
Communication Interface RS232, RS485, USB 2.0 (12 Mbps)
 TTL, SPI, Clock & Data / ABA1,2 / Wiegand26,30,32,40,42,50,56,58 as optional
Contact StandardISO 7816 1/2/3, ClassB,C (3V,1.8V), T=0 and T=1
One build-in SAM slot, expandable on request
Extended I/O port3 I/O ports (Bi-directional USER pin); the I/O ports provide TTL level interface for general-purpose use;
2 LEDs drivers; Module enable / Module reset pins; MFOUT & MFIN
Power Supply3.3V or 5V DC (±5%)
Power Consumption0.45mA in ultra low power mode
80mA( <100 mA) during card polling
Communication Rateup to 848kbps High speed transaction
Baud Rate9600-115200 Kbit/s (default 115200)
AntennaOne External Antenna as below options:
55*50*2.6mm (External Antenna)
40*20*2.6mm (External Antenna)
30*30*2.6mm (External Antenna)
IndicationControllable 2 LED (Red and Green) and 1 Buzzer to observe working status
Operating Temperature -20 to +60°C
Storage  Temperature -25 to +70°C
Humidity0 ~ 95% relative humidity non-condensing
Dimensions100mm*50mm*10mm (with Build-in Antenna) 50mm*46mm*10mm (with External Antenna)
Operating SystemWindows 98/2000/XP/7; Vista; Server2003&2008,ME98; Android; Linux

Specifications are subject to change without notice.

● Access control, hotel lock

● Automatic identification

● Car parking system, Turnstile system

● Payment system, Vending Machine, Koisk system

● Inventory tracking

● Navigation



Document Name Release Date Download
M300 series datasheet Sep-20-2017 download
